Product Details:
|
| Product Name: | Reverse Penetration Water Processor | Production Capacity: | 0.5-100000t/h |
|---|---|---|---|
| Filter Media: | Quartz Sand, Activated Carbon, Resin | Feed Water: | Municipal Tap Water, Surface Water |
| Technique: | Multi-media Filtration+RO+UV | Pump: | CNP Or Grundfos |
| Highlight: | ISO14001 Reverse Osmosis Water Supply System,50m3 RO Water Supply System |
||
RO equipment is reverse osmosis equipment, reverse osmosis equipment is to pass the raw water through a fine filter, granular activated carbon filter, compressed activated carbon filter, etc., and then pressurized by a pump, using a pore size of 1/10000μm (equivalent to the size of E. coli 1/6000, 1/300 of the virus) reverse osmosis membrane (RO membrane), which turns higher-concentration water into low-concentration water, and at the same time isolates industrial pollutants, heavy metals, bacteria, viruses and other large amounts of impurities mixed into the water. , So as to meet the prescribed physical and chemical indicators and sanitary standards for drinking, and produce pure to pure water, which is the best choice for the human body to replenish high-quality water in time. Because the purity of water produced by RO reverse osmosis technology is currently all systems controlled by humans The highest in water technology, the cleanliness is almost 100%, so people call this water production machine a reverse osmosis pure water machine.
System composition
1.Pretreatment system
Generally include raw water pump, dosing device, quartz sand filter, activated carbon filter, precision filter, etc. Its main function is to reduce the pollution index of raw water and other impurities such as residual chlorine to meet the water inlet requirements of reverse osmosis. The equipment configuration of the pretreatment system should be determined according to the specific conditions of the raw water.
2.Reverse osmosis equipment
It mainly consists of multi-stage high-pressure pumps, reverse osmosis membrane elements, membrane shells (pressure vessels), stents, etc. Its main function is to remove impurities in the water and make the effluent meet the requirements of use.
3.Post-processing system
It is an added configuration when reverse osmosis cannot meet the requirements of water output. It mainly includes one or more equipments such as negative bed, positive bed, mixed bed, sterilization, ultrafiltration, EDI and so on. The post-treatment system can better improve the quality of the reverse osmosis effluent, so that it can meet the requirements of use.
4.Cleaning system
It is mainly composed of cleaning water tank, cleaning water pump, and precision filter. When the reverse osmosis system is polluted and the effluent index cannot meet the requirements, it is necessary to clean the reverse osmosis to restore its effectiveness.
5.Electrical control system
It is used to control the normal operation of the entire reverse osmosis system. Including instrument panels, control panels, various electrical protections, electrical control cabinets, etc.
| HJ-Reverse osmosis effluent water quality | ||||||||
| Water quality index | Chroma (degree) | Turbidity(NTU) | Smell | Visible to the naked eye | pH |
aluminum (mg/L) |
iron (mg/L) |
manganese (mg/L) |
| Outlet Water quality | ＜5 | ＜0.2 | No peculiar smell | No | 6.5-8.5 | ＜0.2 | ＜0.2 | ＜0.05 |
| Water quality index |
Total coliform (CFU/100ml) |
Thermotolerant coliforms (CFU/100ml) |
Escherichia coli (CFU/100ml) |
Giardia (pcs/10L) |
Total bacterial count (pcs/ml) |
Total hardness (mg/L) |
Cryptosporidium (pcs/10L) |
Mercury (mg/L) |
| Outlet Water quality | Not detected | Not detected | Not detected | ＜1 | ＜50 | ＜450 | ＜1 | ＜0.001 |
| Water quality index |
Cyanide (mg/L) |
Volatile phenol (mg/L) |
Free chlorine (mg/L) |
Chloroform (mg/L) |
Carbon tetrachloride (mg/L) |
Nitrite(as NO2-) | Lead(as Pb)(mg/L) |
Arsenic (mg/L) |
| Outlet Water quality | ＜ 0.002 | ＜ 0.002 | ＜0.005 | ＜ 0.02 | ＜ 0.001 | ＜ 0.002 | ＜ 0.01 | ＜ 0.01 |
Our advantages are showed below:
Choose us: You choose professional! You choose the rest assured!
